American Range AR-72G-NG 72" Griddle Natural Gas Heavy-Duty Restaurant Range with 2 Ovens - 190,000 BTU
SKU: AR-72G-NG
American Range AR-72G-NG 72" Griddle Natural Gas Heavy-Duty Restaurant Range with 2 Ovens - 190,000 BTU
American Range, restaurant range size 72" x 32-1/2" x 56" Stainless steel front, sides, backriser, shelf, and 6" adjustable legs. Removable full width drip pan. Choose 32,000 BTU/hr. open burners with no-clog lift-off burner heads or 20,000 BTU/hr. 12" section griddle or a combo burner griddle. Griddle comes standard on left. Heavy-duty cast iron grates, 12" x 12". Burner knobs are cool to the touch, high temperature material. Two ovens: 35,000 BTU/hr. standard oven, or 30,000 ВTU/hr. for convection with porcelain interior and inside door panel, oven interior measures 26-1/2"W x 22-1/2"D x 13-1/2"H. Oven thermostat adjusts from 250°F to 500°F. All ovens supplied with two racks. Oven door with a spring assisted, counterweight mechanism requiring no adjustment. Rear gas connection and pressure regulator.
STANDARD FEATURES
- Restaurant Range, gas, 72"
- (1) 72" griddle
- 1" thick plate
- Manual controls
- (2) 26-1/2" standard ovens
- (2) racks each oven
- Stainless steel front, sides
- Choice of high shelf and riser
- 20" riser or 6" stub back
- 6" adjustable chrome plated legs
- 56.0, kW, 190,000 BTU
- cETLus, ETL-Sanitation, Made in USA
- Commercial gas range 72" wide and 32 1/2" depth
- Cooking height 36"
- Stainless steel sides, front, and 6" deep front landing ledge
- Adjustable 6" legs
- Choose: 6" high stainless steel stub back, high riser, or high riser with shelf at no charge
- Base options: Standard, convection, or storage base
STANDARD OVEN
- Sturdy, welded front frame provides stability to the range.
- Pull-off Stainless Steel door for easy cleaning.
- Oven dimensions: 26-1/2”W x 22-1/2”D x 13-1/2”H.
- Thermostat controls temperatre from 150°F to 500°F.
- One chrome plated oven rack. (Additional racks optional).
- Porcelain enamel finish inside oven bottom, sides, back, and door liner.
- Steel burner rated at 35,000 BTU/hr.
- 100% safety gas shut off.
- Matchless push button ignition to light a standing pilot.
GRIDDLES
- Highly polished thick steel griddle plate.
- 3” (76) wide grease drawer.
- One steel tube burner every 12” (305), rated at 20,000 BTU/hr.
- Stainless Steel pilot for each burner for instant ignition.
- Manual control valve for each burner.
- Stainless Steel spatula-width grease trough with landing ledge.
Available Options
- Swivel Casters (set of four – two with front brakes).
- Storage Cabinet Base. (In place of standard oven).
- Thermostatic Control Griddle
-
cETLus -
ETL-Sanitation
Reviews
Manufacturer Stock
Manufacturer Stock
Ships from Manufacturer
- (1) 72" Griddle
- 1" Thick Plate
- Manual Controls
- (2) 26-1/2" Standard Ovens
- Stainless Steel
- 6" Adjustable Legs
Product Specifications
| Manufacturer | American Range |
|---|---|
| SKU | AR-72G-NG |
| Condition | New |
| Length (in.) | 72.00 |
| Depth (in.) | 28.5 |
| Height (in.) | 56 |
| Height Detail | 36 inch high cooking surface |
| Kilowatts | 56 |
| Total BTU | 190,000 |
| Number of Burners | 6 |
| Number of Ovens | 2 |
| Number of Burners | 6 Burners |
| Oven Type | Standard Oven |
| Number of Ovens | 2 |
Documents
American Range Commercial Cooking Equipment
Based in Pacoima, California, American Range’s products are mainly concerned with cooking the food. Roasting, grilling, broiling, and griddling on a commercial scale. Apparatus available include deck pizza ovens, hot plates, salamanders, and fryers along with specialty kitchen equipment like Mongolian barbeque grills and verticle gyro grilling machines.
2 Year Limited Warranty
For Commercial Use Only
