American Range AF-50HE-LP 50 lb. Full Size Stainless Steel High Efficiency Liquid Propane Gas Fryer - 75,000 BTU
American Range AF-50HE-LP 50 lb. Full Size Stainless Steel High Efficiency Liquid Propane Gas Fryer - 75,000 BTU
Bullets list
- Full Size Frypot
- High-Efficiency Power
- All Stainless Steel
- 6" Adjustable Chrome Legs
American Range AF-50HE-LP 50 lb. Full Size Stainless Steel High Efficiency Liquid Propane Gas Fryer - 75,000 BTU
You get a faster and better fryer The Culinary Series by American Range, with the latest technology incorporated into its design, and tons of features and benefits to suit the everyday demanding needs especially during extreme operating periods. Bringing added value and assured performance, by offering superior recovery. The ample cool zone prevents food particles from carbonization while extending oil life. Our unique vessel tank design features a deeper oil level, for larger food products, and a sloping vessel bottom for quick and complete draining of oil and debris.
Its special design tube shields provide a uniform heating pattern for positive, more consistent frying results. Equipped with a Millivolt Control System, and a 100% safety shut off valve. No electrical power is required. Conveniently located controls for easy access for operators, maintenance and service. All Stainless Steel heavy duty exterior. Durable, double panel door, rugged base and removable Stainless Steel basket guide. Equipped with two nickel plated baskets with cool grip plastic coated handles provide maximum operator comfort.
Quality, dependability and customer satisfaction make American Range the brand of choice among professional chefs and restaurateurs worldwide.
Standard Features:
- Stainless Steel high quality construction.
- Stainless steel durable double layer access door.
- 304 stainless steel fry pots for long life.
- Stainless steel side panels.
- Millivolt control system, no electrical hook up required.
- Thermostatic control adjusts from 200°F to 400°F.
- 100% safety gas shut of when temperature exceeds safe limit.
- 3/4” NPT gas inlet in rear of unit.
- Chrome plated catch rack under the fry baskets.
- 3/4” diameter opening drain valve for easy draining of oil.
- Twin chrome plated fryer baskets with cool grip plastic coated handles for safety & ease.
- 6” high chrome plated adjustable legs.
- Regulator with built-in gas valve.
- Deflector/bafes absorb and difuse heat to tube walls, providing fast and efcient heating.
- Combination gas valve includes built in pressure regulator, and gas control system, hermetically sealed for operating stability.
- High Efficiency Power - 3 each 25,000 BTU's/hr. Burners (total 75,000 BTU's)
- 50 Lb tank oil capacity
- High-Limit Safety Switch Standard
- Two year limited warranty, parts and labor.
Optional Features:
- Stainless Steel tank cover.
- Casters (2 locking).
- Matching “Dump Station”.
- Stainless steel splash guard (removable & tool-less).
- Heat lamp for model #ARFDS, Stainless Steel work top/side tray.
- Stainless Steel side tray with pan & cut out.
- Stainless Steel Spreader work top solid surface. 12”, 18” & 24”.
- Quick disconnect and flexible gas hose.
Approvals
-
NSF
-
ETL
-
AGA
Documents
Product Specifications
Manufacturer | American Range |
---|---|
SKU | AF-50HE-LP |
Condition | New |
Length (in.) | 15.50 |
Depth (in.) | 30.5 |
Height (in.) | 45.75 |
Kilowatts | 22 |
Approval | NSF, ETL, AGA |
Total BTU | 75000 |
Capacity | 50 lb. |
Number of Burners | 3 Burners |
