Glastender DI-IS24-LF 24" x 19" Drop-In Ice Bin

At Glastender, we've built our reputation as pioneers in bar fabrication, refrigeration, and more. Now we're looking for leaders like you to help us shape the future.

• Ice & Water Unit, drop-in, 24"W x 19"D OA
• Insulated ice chest with 10-1/2" deep liner & ABS breaker strip
• 33 lbs ice capacity
• Includes sliding 2-piece stainless steel cover
• 9-1/4" wide x 11-1/2" front-to-back x 6" deep sink bowl
• 4" OC deck mount faucet holes (faucet not included)
• Stainless steel top, ice bin liner, & sink
• Galvanized exterior wrap & bottom
• 22-1/2" x 17-1/2" cutout required
• ETL-Sanitation

• Manufactured with total welded construction to meet all NSF standards
• Stainless steel top, interior liner, and sink bowl
• Unique hemmed edge for added strength and visual appeal
• 9-1/4" by 11-1/2" by 6" deep sink bowl
• Includes four 1/4-20 x 1-1/2" studs for mounting to countertop
• Includes 1-1/2" IPS drain fitting
• PVC plastic breaker strip around ice bin liner: creates 5/16" raised edge around liner, acts as thermal barrier to prevent heat transfer, and makes the cover slide easier
• Sliding stainless steel cover
• Eco friendly foamed-in-place insulation has zero impact on global warming or ozone depletion
• Galvanized steel exterior wrap
• 10-1/2" deep liner
• Heavy-duty faucet is standard (available less faucet by adding the suffix '-LF' to the model number)
• ETL Sanitation Listed, Intertek 4004503, Conforms to NSF/ANSI STD 2, Certified to CSA STD B45.4

• Drains:
  • Sink: 1-1/2" I.P.S. Threaded drain will fit Dearborn part #8033 slipnut and part #W-573P washer
  • Ice Bin: 1-1/2" tail piece
• Faucet (not included with -LF models):
  • DI-IS24: Deck mount on 4" centers, accepts 3/8" sink leads, hot and cold water connections required
  • DI-IW24: Deck mount water filler, accepts 3/8" sink lead, cold water connection required
• Sink Bowl Dimensions: 9-1/4" by 11-1/2" by 6" deep
• Cover: Two piece sliding cover, stainless steel, included with all models
• Ice Bin Liner Depth: 10-1/2"
• Ice Capacity: 33 lbs
• Cut-out Dimensions: 17-1/2" by 22-1/2"
• Materials:
  • 20 gauge stainless steel parts include: all components unless otherwise noted
  • 16 gauge galvanized steel part include: faucet support bracket; 22 gauge galvanized steel parts include: exterior wrap and bottom
