Glastender C-IBA-6 6" x 19" 17 lbs. Underbar Ice Bin

At Glastender, we've built our reputation as pioneers in bar fabrication, refrigeration, and more. Now we're looking for leaders like you to help us shape the future.

• CHOICE Underbar Ice Bin
• 6"W x 19"D
• 17 lbs. ice capacity
• Open channel for beverage line access
• 10-1/2" deep bin liner
• PVC plastic breaker strip around ice bin liner
• Stainless steel construction
• ETL-Sanitation (not freestanding) (NOTE: Made to order not returnable)

• All stainless steel construction
• One-piece, seamless top and backsplash
• PVC plastic breaker strip around ice bin liner: creates 5/16" raised edge around liner, acts as thermal barrier to prevent heat transfer, and makes the cover slide easier.
• Tubing chase available centered in backsplash of 12" and larger models. Specify accessory model #TC-BS.
• Backsplash mounted, hot and cold water ice-melting faucet available. Specify accessory model # IMF (12" wide and larger models only).
• Available in 6" incremental lengths from 6" to 48"
• 24" deep version provides larger ice bin not just a deck extension on the back of the 19" deep model
• Sliding stainless steel cover
• Eco friendly foamed-in-place insulation has zero impact on global warming or ozone depletion
• Adjustable stainless steel bullet feet
• Ten circuit available with all 24" and wider models (add suffix '-CP10' to model number)

• C-SR-X — Single speed rail, where X is specified as the length in inches.
• C-DR-X — Double speed rail, where X is specified as the length in inches.
• IBCA-X or IBCB-X — Two-piece, sliding stainless steel cover for 19" (A) or 24" (B) deep models, respectively, where X is specified as the length of the ice bin in inches. Deduct 6" from cover length for one bottle well and 12" for two bottle wells.
• BW3 or BW4 — 3 or 4 bottle well for potable ice for 19" (A) or 24" (B) deep models, respectively. May be positioned left or right. If two are ordered, they are positioned one at each side.
• BR3 or BR4 — 3 or 4 bottle rack for non-potable ice for 19" (A) or 24" (B) deep models, respectively. One rack may be ordered for each 6" of ice bin length. Not for use with sliding cover. Not for use with 6" ice bins.
• CCD — Condiment dispenser
• IBD-H-A or IBD-H-B — Ice bin divider for 19" (A) or 24" (B) deep models, respectively.

Drain
• Non-cold plate model: 1-1/2" tailpiece
• Ten circuit cold plate model '-CP10': 3/4" MPT

Cold Plate (models with '-CP10-ED' suffix)
• Ten circuit available with all 24" and wider models
• Connection is 5/16" O.D. stainless steel tubing with swaged end

Liner Depth
• 10-1/2"

Legs
• 1-5/8" diameter, 16 gauge stainless steel
• Stainless steel bullet feet

Materials
• 20 gauge stainless steel
• PVC plastic breaker strip around ice bin liner
