CWSH2424-G 24"D x 24"L 3 Burner Galvanized Interior Smokehouse Oven
$1,407.00
Estimated to Ship in 4-7 Business Days
| Manufacturer | LJ Manufacturing |
|---|---|
| SKU | CWSH2424-G |
| Condition | New |
| Length (in.) | 24.00 |
| Depth (in.) | 24 |
| Height (in.) | 78 |
| Approval | NSF, AGA |
| Total BTU | 75000 |
View Spec Sheet
Spec sheet
Approvals
NSF, AGA
Commercial Use Only
View more from LJ Manufacturing
Description
• Stainless steel interior and exterior, type 430, fully insulated with 1" density block type fiberglass
• Door-double wall construction, fully insulated, reinforced & recessed into front opening, with 3 heavy duty hinges & 2 swivel latches
• Oven-fitted resistant steel drip guards & removable ceiling panels
• Stainless steel drip pans set over heavy duty baffle plate and fitted with protective anti splash grating
• Gas burners-double port tubular burners controlled by individual gas valves are housed in the insulated chamber below baffle plate
• Positive ignition is provided with separate pilot gas valve and pilot burner extending across individual gas burners, 75,000 BTU each
• All insulation must be under the hood
• NSF Certified
OPTIONAL FEATURES
• AGA Standard is optional (Regulator, Thermostat, Safety Valve). The American Gas Association (AGA) standards address the design, installation and maintenance of natural gas operations.
• Left or Right door hinge
• Thermometer Gauge
• Casters
• All other dimensions are avialable made to order
PARTS & ACCESSORIES
• Single, Double, Triple, and Tetrad burner type
• Small or Large shelf size
• Small or Large water pan size
• S/S or Galvanized crossbar
Stainless Steel Exterior, Galvanized Interior, and Fully Insulated. THIS IS NOT A WOOD CHIP SMOKER
STANDARD FEATURES• Stainless steel interior and exterior, type 430, fully insulated with 1" density block type fiberglass
• Door-double wall construction, fully insulated, reinforced & recessed into front opening, with 3 heavy duty hinges & 2 swivel latches
• Oven-fitted resistant steel drip guards & removable ceiling panels
• Stainless steel drip pans set over heavy duty baffle plate and fitted with protective anti splash grating
• Gas burners-double port tubular burners controlled by individual gas valves are housed in the insulated chamber below baffle plate
• Positive ignition is provided with separate pilot gas valve and pilot burner extending across individual gas burners, 75,000 BTU each
• All insulation must be under the hood
• NSF Certified
OPTIONAL FEATURES
• AGA Standard is optional (Regulator, Thermostat, Safety Valve). The American Gas Association (AGA) standards address the design, installation and maintenance of natural gas operations.
• Left or Right door hinge
• Thermometer Gauge
• Casters
• All other dimensions are avialable made to order
PARTS & ACCESSORIES
• Single, Double, Triple, and Tetrad burner type
• Small or Large shelf size
• Small or Large water pan size
• S/S or Galvanized crossbar
